CNC Router
CNC Router — Standard Series
CZ-CNC-1325
Standard-series CNC router available in five bed sizes from 1200×1200 to 2000×4000 mm.
- Standard-series CNC router available in five bed sizes from 1200×1200 to 2000×4000 mm.
- Spindle from 1.5 to 7.5 kW at up to 24,000 rpm for wood, MDF, acrylic and composite panel.
- Carving speed to 8000 mm/min and rapid traverse to 15,000 mm/min.
Select size
- CNC routing / milling
- Acrylic
- Wood / MDF / plywood
- Foam / EVA
- PVC / ABS
- Composite panel (ACP)
Specifications
Specifications — 1300×2500 (1325)
| Technical parameter | 1300×2500 (1325) |
|---|---|
| Working area | 1300×2500 mm |
| Machining accuracy | ±0.08 mm |
| Spindle motor | 1.5–7.5 kW spindle |
| Spindle speed | 6000–24000 rpm |
| Tool diameter | φ3.175 / φ6 / φ12.7 mm |
| Maximum carving speed | 8000 mm/min |
| Maximum aerodynamic speed | 15000 mm/min |
Why this machine
Built for the work
Standard-series CNC router available in five bed sizes from 1200×1200 to 2000×4000 mm.
- Standard-series CNC router available in five bed sizes from 1200×1200 to 2000×4000 mm.
- Spindle from 1.5 to 7.5 kW at up to 24,000 rpm for wood, MDF, acrylic and composite panel.
- Carving speed to 8000 mm/min and rapid traverse to 15,000 mm/min.
On the shop floor
What you can make
